Classification: CNG Filling Station
Release time: 03-30-2024
Number of views: 64
Product details
Main Technical Parameters and Features:
Working Medium: Compressed Natural Gas
Measurement Accuracy: ±0.5%
Flow Rate: 1-30 Nm3/min per nozzle; 2-40 Nm3/min per nozzle
Rated Working Pressure: 20 MPa
Working Pressure: ≤25 MPa
Ambient Temperature: -40°C to +50°C
Explosion Protection Class: ExibdmeIIAT4
Operating Power Supply: 220V ±15%; 50Hz ±1Hz
Measurement Unit: Nm3
Minimum Reading Division: 0.01 Nm3
Single Transaction Count Range: 0 to 9999.99 Nm3, yuan, kg
Cumulative Count Range: 0 to 99999999.99 Nm3, yuan, kg
Unit Price Setting Range: 0 to 99.9 yuan/Nm3
